Flat PDLC Switchable Smart Glass Electrochromic Glass Film
| Place of Origin | China |
|---|---|
| Brand Name | VALUES GLASS |
| Certification | Upon Request |
| Model Number | Smart Glass |
| Minimum Order Quantity | 5 pieces |
| Price | Negotiable |
| Packaging Details | Plywood Pallet or per request |
| Delivery Time | 14 Days |
| Payment Terms | T/T, L/C, Western Union |
| Supply Ability | 10,000 sq.meter/Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product | Switchable Smart Glass | Shape | Flat, Curved |
|---|---|---|---|
| Material | Clear Glass | Application | Windows, Door, Office, Bank, Hotel, Hospital |
| Film Color | Clear, Milky, Grey, Blue, Green, Red | Thickness | 5+5mm, 6+6mm, Etc |
| Size | Customized | Function | Privacy, Safety |
| High Light | Electrochromic Film Smart Privacy Glass,Flat Switchable Privacy Glass,Switchable Frosted Glass PDLC |
||
Product Description
PDLC Switchable Smart Electrochromic Glass Film
| Product Description | 65V High Transparent Switchable PDLC Film |
|||||
| Operation Model | Power On | Transparent | ||||
| Power Off | Opaque | |||||
| Optical Performance | Avaliable Colour | Milky White | Dark Grey | |||
| Haze(on) | 4-5% | 4-5% | ||||
| Haze(off) | >90% | >90% | ||||
| View Angle | About 145 Degree | |||||
| Light Transmittance( On) | 90% | 32% | ||||
| Light Transmittance( off) | 4% | 4% | ||||
| UV Block | >99% | |||||
| Infrared Block | On Model>17% Off Model >80% | |||||
| Size | Maxmium | Self-adhesive Film Roll Size:1*50M,1.2*50M,1.5*50M ,1.8*50M(standard type) Non-adhesive Film Roll Size:1*50M,1.2*50M,1.5*50M,1.8*50M,2.0*50M(standard type) |
||||
| Thickness | 0.4mm | |||||
| Electrical Performance | Operating Voltage | AC65±5V | ||||
| Power Consumption | About 3.7W/SQM | |||||
| Frenquency Rate | 50-60HZ | |||||
| Operating Temperature | - 20℃-- 70 ℃ | |||||
| Switch Time | Less than 1 second (Off→On :about 200 milliseconds On→Off :about 600 milliseconds) | |||||
| Life Time | More than 100000h(20years) | |||||
| Other Functions | Dimmer Function | YES | ||||
| Projection Screen | YES | |||||
| Warranty Time | Two years | |||||
| Project | Status | Parameter |
| Size | / | 1.2/1.5*50m |
| Thickness | / | 0.5mm |
| Transmittance | ON | 79% |
| OFF | 5% | |
| Haze | ON | 5.5% |
| OFF | 90% | |
| Viewing Angle | ON | 120° |
| UV Resistance | ON | >50% |
| OFF | >98% | |
| Voltage | ON | AC 60V |
| Reaction Time | ON-OFF | 50ms |
| OFF-ON | 10ms | |
| Power Consumption | ON | 6w/sqm |
Application of Switchable Smart Glass:
- Executive offices and conference room
- Control room of government facilities
- Family household and apartments
- Storefronts & Windows
- Privacy / security glass
- Glass walls doors
- Partitions / Vision panels
Other Products we offer:
-- Tempered glass;
-- Insulated glass;
-- Laminated glass;
-- Smart glass & self-adhesive PDLC film;
-- Non-reflective glass panels, anti-glare glass panels;
-- Vacuum glass;
-- Stained / fused glass;
-- LED glass, LED mirror;
Our advantage:
- Our smart glass could be produced with two methods, with autoclave and with oven.
- Our smart glass has the best transparency when power on , least haze, and it has a good privacy function when power off.
- Both flat and bent smart glass could be provided as per design request.
- Professional seaworthy wooden crate packing for LCL and client receive it safely.
- Best Service before and after sales.
- Best technical support from our professional team with years experience.
Why choose us:
- Competitive price, value for money
- Expertise on glass & mirror products
- Prompt communication & service
- Quality products
- On Time Delivery
- Flexible on order qty & consolidation
| Item | state | Smart film | Smart glass | ||
| Optical Properties | Visible Light Transmission | ON | ≥80% | ≥78% | |
| OFF | ≤5% | ≤52% | |||
| Parallel Light Transmission | ON | ≥79% | |||
| OFF | ≤5% | ||||
| Visual Angle | ON | 150 | 120 | ||
| UV Blocking | ON/OFF | ≥99% | |||
| Haze | ON | ≤5% | |||
| OFF | ≤92% | ||||
| Heat Resistance | R/RO | 0.8-1.1 | |||
| Electrical Properties | Operating Voltage | ON | AC60V or AC40V | ||
| Power Consumption | ON | 12.5W/m² | |||
| AC.Transformer | / | 50W,100W,200W,300W/SET | |||
| Specification | Thickness | / | 0.38mm | 9-24mm | |
| Max Width | / | Self-adhesive | Non-adhesive or glass | ||
| / | 1500mm | 1580mm | |||
| Color | / | White,dark gray,light gray,blue,green,pink,red | |||
| Life time | / | More than 50000hrs | |||
| Working Temperature | / | / | -20-60°C | ||
