High Transparency 0.65mm PDLC Switchable Privacy Smart Glass Film
| Place of Origin | China |
|---|---|
| Brand Name | VALUES GLASS |
| Certification | Upon Request |
| Model Number | Smart Glass |
| Minimum Order Quantity | 5 pieces |
| Price | Negotiable |
| Packaging Details | Plywood Pallet or per request |
| Delivery Time | 14 Days |
| Payment Terms | T/T, L/C, Western Union |
| Supply Ability | 10,000 sq.meter/Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product | Switchable Smart Glass | Material | Clear Glass |
|---|---|---|---|
| Structure | Solid | Technique | Lamination |
| Color | Clear, Milky, Grey, Blue, Green, Red | Shape | Flat, Curved |
| Thickness | 5+5mm / 6+6mm | Application | Door, Office, Bank, Hotel, Hospital |
| Highlight | 0.65mm Smart Privacy Film,PDLC Privacy Smart Glass,0.65mm Switchable Smart Glass Film |
||
Product Description
High Transparency Switchable Smart Glass for Keeping Privacy Used for Hospital
Description of Switchable Smart Glass:
SMART GLASS is a layer of liquid crystal film sandwiched between two pcs of glasses. Liquid crystal film is protected between 2 layer of PVB film, then placed in an autoclave or a general one-step high temperature oven to glue together during high-pressure process. SMART GLASS has advantage against privacy protection, along with the features of safety glass. Glass will be transparent if there is current on LC film or opaque when power off. Light and darkness can be changed by controlling the voltage, easy to switch, convenient and simple. If black film used it will be opaque when power off, or black transparent when energized. Color can also be done in accordance with the customer, the film can be made with a self-adhesive membrane function according to customer requirements. Control can be achieved in various ways, such as light control, sound control, temperature control, remote control and touch control.
What Is Pdlc Smart Glass Film?
Pdlc Smart Film also call privacy smart film, smart pdlc film, switchable pdlc film, switchable privacy smart pdlc film, smart glass pdlc film, smart glass film. It is state of the art laminated glass with a PDLC film interlayer between two sheets of 5mm safety tempered glass. The PDLC film is two layer PET-ITO conducting film + Middle inside (LCD) Liquid Crystal Membrane.
The smart film is an intelligent high function glass film, which has a special characteristic of changing between translucent and opaque by voltage control. When power off, coming visible light scatters through the PDLC, and the film turns translucent; When power on, coming visible light transmits the PDLC and the film turns clear.
Application of Switchable Smart Glass:
- Water proof smart glass
- Bullet proof smart glass
- Smart glass door / windows, smart glass partitions
- Smart glass bathroom
- Smart glass projection screen
- Hollow sound insulation smart glass
- Energy saving and environmental protection smart glass
- Colorful smart glass/Digital printing dimmer Glass
- Anti-skid smart glass
- LED smart glass
- UV protect smart glass
Parameter of Switchable Smart Glass:
| Power ON | Power OFF | ||||
| Light transmittance: | Parellel light: | >=66% | <=1.5% | ||
| Visible light: | Common Film | >=83% | >=55% | ||
| High Transmittance Film | >=88% | >=57% | |||
| Haze: | <=3% | >=90% | |||
| Response time: | <10ms | <200ms | |||
| Viewing angle: | >=150° | ||||
| Voltage: | Input: | AC220V, AC110V, DC24V, DC12V | |||
| Operating voltage: | AC48V | ||||
| Threshold voltage: | <=20V | ||||
| Frequency: | Operating frequency: | 30~400Hz | |||
| Optimum operating frequency: | 50Hz | ||||
| Power consumption: | <=5W/m2 | ||||
| Continued opening time: | >80,000h | ||||
| Continued ON and OFF times: | >80,000,000 | ||||
| Insulation Resistance: | >2M Ω | ||||
| Operating temperature: | Between -10℃ and 65 ℃. | ||||
| Storage temperature: | Between -20℃ and 80 ℃. | ||||
| Thickness: | 0.65mm | ||||
| Max dimension: | Individual piece | <=1.5 * 3.2 meters | |||
| Roll | 0.93/1.2/1.5(W) x 20/30/50M(L) | ||||
| Adhesion for silicon glue & glass: | 20g/mm | ||||
| Adhesion for PDLC film: | 50g/mm |
||||
Our advantage:
- Our smart glass could be produced with two methods, with autoclave and with oven.
- Our smart glass has the best transparency when power on , least haze, and it has a good privacy function when power off.
- Both flat and bent smart glass could be provided as per design request.
- Professional seaworthy wooden crate packing for LCL and client receive it safely.
- Best Service before and after sales.
- Best technical support from our professional team with years experience.
Main products ranges:
-- Tempered glass;
-- Insulated glass;
-- Laminated glass;
-- Smart glass & self-adhesive PDLC film;
-- Non-reflective glass panels, anti-glare glass panels;
-- Vacuum glass;
-- Stained / fused glass;
-- LED glass, LED mirror;
About Us:
VALUES GLASS, a continuous growing company, located in Shanghai, China.
Since year of 2005, we stepped on furnish glasses;
Since year of 2010, our ranges are expanded to building glasses;
Since year of 2014, VALUES GLASS in Shanghai is established to meet business growth;
VALUES GLASS, aim to deliver ADDED VALUE for partners by:
-- Competitive price;
-- Quality products;
-- On time delivery;
-- Efficient communication;
VALUES GLASS, contribute to partners’ success with our expertise & knowhow!
Packaging & Delivery:
Standard export package: Plywood or wooden crate
Corner protector and protective film is available
Crates shall be banded by steel bands
