6.38mm EVA Safety Tempered Etched Stair Glass Bannister Panels
|Product Name||Tempered Glass Panels||Material||Float Glass|
|Color||Clear, Green, Blue, Grey, Bronze||Thickness||3-19mm|
|Shape||Curve, Flat||Edge||Safety Edge Or As Your Demand|
|Function||Decorative Glass, Heat Reflective Glass|
6.38mm glass bannister panels,
BS6206 glass bannister panels,
6.38mm etched glass stair panels
Safety Tempered Glass manufacturer For Stair Balustrades, Garden Fencing, Pool Fencing
What is Tempered Glass Panels:
Tempered glass is made much stronger than ordinary glass due to a special treatment. It's also called toughened glass or safety glass. The strength of toughened glass or tempered glass can be up to five times stronger than ordinal glass. The procedure for turning glass into toughened glass or tempered glass is above all a thermal treatment. The glass is heated until more than 600°C. And then it is cooled very quickly with the result that the glass shrinks. It enhances the mechanical strength and thermal shock resistance of the glass itself, and has a special fragment state, which will reduce the harmful to human when the tempered glass is broken.
Advantage of Tempered Glass Panels:
1. Strength improvement: The mechanical strength, impact resistance and bending strength of tempered glass can reach 4 to 5 times that of ordinary glass.
2. Improved thermal stability: Tempered glass can withstand huge temperature differences without being damaged, and its resistance to temperature differences is 3 times that of ordinary float glass of the same thickness.
3. Improved safety: After the toughened glass is damaged by a strong force, tiny obtuse-angle particles will appear quickly, thereby ensuring personal safety to the greatest extent.
Specification of Tempered Glass Panels:
|Product Name||Safety Tempered Glass manufacturer For Stair Balustrades, Garden Fencing, Pool Fencing|
|Raw Material||Clear Glass, Ultra Clear (Low Iron) Glass, Tinted Glass|
|Glass Process||Heat treatment or Chemical treatment|
|Glass Color||Clear, Blue, Green, Bronze, Grey and etc|
|Thickness||2.1 mm - 19 mm|
|Max dimension||3660 x 2440 mm|
|Min dimension||20 x 20 mm|
|Glass Shape||Flat or Curved / Bent|
|Fragment (Area 5*5cm)||T<=3mm, Fragment>=30 PCS; 4mm<=T<=12mm, Fragment>=40 PCS|
|Shock resistance||5~7 times of annealed glass|
|Heat resistance||Thermal shock at about 300℃|
|Withstand pressure||3~5 times of annealed glass|
|Holes or cutout||Drawing or sketch is needed|
|Printing||Available per request|
Applications of Tempered Glass Panels:
- Doors and windows
- Frameless shower doors
- Partitions for homes, offices, hotels and other commercial buildings
- Glass Curtain Wall and Facades
- Skylight glass, Glass stairs, and Glass elevators
- Tabletops Glass
- Glass shelves and Cabinets
- Fireplaces Glass
- Other glass decorative panels in interior design
Q1: How can we get detailed price?
-- Please provide us product thickness, size & qty, which will help us calculate costs for you.
-- CIF price is also available if destination port is provided.
Q2: How about sample and freight cost?
-- In general, we provide free samples, customers take freight cost.
Q3: How long is the production lead time for mass order?
-- It will take about 1~3 weeks, depends on product complexity & order quantity.
Q4: How do you control product quality?
-- Clearly understand customers’ product requirements;
-- To transfer customers requirements to internal product documents;
-- Complete quality assurance system from IQC to OQC. Outgoing inspection record is available for each order.
Q5: What about the payment?
-- T/T, L/C, Ali Trade Assurance, Western Union.
Q6: What about the after-sales service?
-- Normally we response within 4 hours, by email or WhatsApp or Wechat etc;
