Energy Saving 8.3mm Vacuum Insulated Glass Heat Insulation For Skylight

Good quality Insulated Glass Panels for sales
Good quality Insulated Glass Panels for sales
I'm Online Chat Now

Energy Saving 8.3mm Vacuum Insulated Glass Heat Insulation For Skylight

China Energy Saving 8.3mm Vacuum Insulated Glass Heat Insulation For Skylight supplier

Large Image :  Energy Saving 8.3mm Vacuum Insulated Glass Heat Insulation For Skylight

Product Details:

Place of Origin: China
Brand Name: VALUES GLASS
Certification: Upon Request
Model Number: Vacuum Glass

Payment & Shipping Terms:

Minimum Order Quantity: 1 Pcs
Price: Negotiable
Packaging Details: Plywood Pallet or per request
Delivery Time: 14 Days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 8,000 sq.meter/Month
Contact Now
Detailed Product Description
Raw Material: Clear Glass, LOW E Glass, Low Iron Glass U Value: 0.4W/(m2*K)
Thickness: 8.3mm Glass: Fully Tempered, Half Tempered
Application: Window, Door, Curtain Wall, Skylight Product Name: Vacuum Insulated Glass

Vacuum Glass Vacuum Insulated Glass Energy Saving Glass Vacuum Laminated Glass



Features:

1. Insulating properties: excellent thermal insulation properties, can effectively reduce the heat transfer coefficient U value, maintaining indoor space more comfortable.

2. Anti-condensation properties: As the layer of insulating glass gas interval with good insulation properties, making the inner and outer glass, insulating glass case of heating in the winter with a large temperature difference, but with a very small difference in temperature between the glass. So it has good anti-condensation properties.

3. Noise performance: Hollow glass can be reduced about 34 db noise can be reduced to 80 dB 45 dB traffic noise, very quiet level.

4. Beautiful: can use different colors to achieve a good aluminum spacers in a decorative effect.

Product Description:

Product Name Vaccum Glass
Raw Material Glass Clear Glass, LOW E glass, Low Iron Glass
Thickness 8.3mm
Max Size

1,500*2,500mm

Min Size 300 * 300mm
U Value 0.4W/(m2*K)





Theory & Structure:

Vacuum glass is based on the proven vacuum thermos bottle.



By separating two panes of glass with small pillars and sealing the edges, a micro-void space is created between the two panes, all of the air is removed. The height of the void space between the panes is kept 0.2 mm by the tiny pillars, and the vacuum is pulled down to 10-4 Pa.

Energy Saving 8.3mm Vacuum Insulated Glass Heat Insulation For Skylight

Energy Saving 8.3mm Vacuum Insulated Glass Heat Insulation For Skylight




Combination:

Due to the inside vacuum, the conduction and convection of heat between the panes is almost nil. In addition, the LOW-E coating reflects more than 85% of the infrared back into the room. For these reasons, vacuum glass windows prevent nearly all heat loss from conduction, convection and radiation.

Energy Saving 8.3mm Vacuum Insulated Glass Heat Insulation For Skylight







Advantage:

-- Better U Value, Less Weight.

Energy Saving 8.3mm Vacuum Insulated Glass Heat Insulation For Skylight

Energy Saving 8.3mm Vacuum Insulated Glass Heat Insulation For Skylight



Energy Saving 8.3mm Vacuum Insulated Glass Heat Insulation For Skylight



Energy Saving 8.3mm Vacuum Insulated Glass Heat Insulation For Skylight



Energy Saving 8.3mm Vacuum Insulated Glass Heat Insulation For Skylight





Energy Saving 8.3mm Vacuum Insulated Glass Heat Insulation For Skylight
