Explosion Proof Privacy 5W/M2 PDLC Smart Tint Window Film

Place of Origin China
Brand Name VALUES GLASS
Certification Upon Request
Model Number Smart Glass
Minimum Order Quantity 1 Pcs
Price Negotiable
Packaging Details Plywood Pallet or per request
Delivery Time 14 Days
Payment Terms T/T, L/C, Western Union
Supply Ability 10,000 sq.meter/Month
Product Details
Product Switchable Smart Glass Material Clear Glass
Structure Solid Technique Lamination
Shape Flat, Curved Thickness 5+5mm / 6+6mm Or Etc...
Application Door, Office, Bank, Hotel, Hospital Color Clear, Milky, Grey, Blue, Green, Red
High Light

Milky PDLC Smart Film

,

5W/M2 Smart Tint Window Film

,

5W/M2 Smart Tint PDLC Film

Leave a Message
Product Description

PDLC Film Switchable Smart Glass Electric Privacy Smart Window and Door



Features of Switchable Smart Glass:



(1) Privacy partition: The biggest function of smart glass is the privacy protection function, which can control the transparent and opaque state of the glass at any time, and have a strong spatial extension effect, privacy, openness, and freedom.

(2) Sound insulation and noise reduction: The smart film in the middle of the glass has a blocking effect on noise, and the anti-noise ability is increased by more than 20% compared with ordinary glass.

(3) Touch projection: Smart glass is still this very excellent projection hard screen. In a suitable light environment, if you choose a high-lumen projector, the projection imaging effect is very clear and outstanding. (Recommended to use rear projection imaging method)

(4) Heat insulation and sun protection: The smart film in the middle of the dimming glass can insulate and block more than 99% of ultraviolet rays and 98% of infrared rays. Shield some infrared rays to reduce heat radiation and transmission. And shielding ultraviolet rays can protect indoor furnishings from fading and aging due to ultraviolet radiation, and protect personnel from diseases caused by direct ultraviolet rays.

(5) Safety and explosion-proof: The middle-layer smart film can tightly absorb glass fragments when the glass is hit by high intensity, effectively preventing glass splashing and hurting people.



Description of Switchable Smart Glass:



Laminated Switchable Smart Glass Used for Privacy Protection. This smart glass is based on PDLC (Polymer Dispersed Liquid Crystal) technology. It is a new type of special photoelectric glass product, which is composed of liquid crystal film in the middle of two-layer glass and synthesized by high temperature and high pressure. As a new material, it can be made into various glass doors or partition walls, and widely used in offices, shop windows, banks, hotels and other places.



Application of Switchable Smart Glass:



  • Smart glass doors
  • Smart Glass windows
  • smart glass partitions
  • Smart glass bathroom
  • Smart glass projection screen
  • Hollow sound insulation smart glass
  • Energy saving and environmental protection smart glass
  • Colorful smart glass/Digital printing dimmer Glass
  • Anti-skid smart glass
  • LED smart glass
  • UV protect smart glass
  • Water proof smart glass
  • Bullet proof smart glass

Explosion Proof Privacy 5W/M2 PDLC Smart Tint Window Film 0



Parameter of Switchable Smart Glass:



  Power ON Power OFF
Light transmittance: Parellel light: >=66% <=1.5%
Visible light: Common Film >=83% >=55%
High Transmittance Film >=88% >=57%
Haze: <=3% >=90%
Response time: <10ms <200ms
Viewing angle: >=150°
Voltage: Input: AC220V, AC110V, DC24V, DC12V
Operating voltage: AC48V
Threshold voltage: <=20V
Frequency: Operating frequency: 30~400Hz
Optimum operating frequency: 50Hz
Power consumption: <=5W/m2
Continued opening time: >80,000h
Continued ON and OFF times: >80,000,000
Insulation Resistance: >2M Ω
Operating temperature: Between -10℃ and 65 ℃.
Storage temperature: Between -20℃ and 80 ℃.
Thickness: 0.65mm
Max dimension: Individual piece <=1.5 * 3.2 meters
Roll 0.93/1.2/1.5(W) x 20/30/50M(L)
Adhesion for silicon glue & glass: 20g/mm
Adhesion for PDLC film: 50g/mm




Why Choose Us:


  • Professional and Good Service
  • Good quality and Fast Delivery
  • Best Service before and after sales
  • Best technical support from our professional team with years experience
  • Professional seaworthy wooden crate packing for LCL and client receive it safely
  • Our smart glass could be produced with two methods, with autoclave and with oven
  • Our smart glass has the best transparency when power on , least haze, and it has a good privacy function when power off
  • Both flat and bent smart glass could be provided as per design request

Main products ranges:



-- Tempered glass;

-- Insulated glass;

-- Laminated glass;

-- Smart glass & self-adhesive PDLC film;

-- Non-reflective glass panels, anti-glare glass panels;

-- Vacuum glass;

-- Stained / fused glass;

-- LED glass, LED mirror;



Explosion Proof Privacy 5W/M2 PDLC Smart Tint Window Film 1

About Us:


VALUES GLASS, a continuous growing company, located in Shanghai, China.



Since year of 2005, we stepped on furnish glasses;

Since year of 2010, our ranges are expanded to building glasses;

Since year of 2014, VALUES GLASS in Shanghai is established to meet business growth;



VALUES GLASS, aim to deliver ADDED VALUE for partners by:
-- Competitive price;
-- Quality products;
-- On time delivery;

-- Efficient communication;



VALUES GLASS, contribute to partners’ success with our expertise & knowhow!

Packaging & Delivery:



Standard export package: Plywood or wooden crate

Corner protector and protective film is available

Crates shall be banded by steel bands
