6A / 9A/ 12A / 15A Reflective Insulated Glass For IGU Glass Hollow Glass

Place of Origin China
Brand Name VALUES GLASS
Certification Upon Request
Model Number Insulated Glass
Minimum Order Quantity 5 pieces
Price Negotiable
Packaging Details Plywood Pallet or per request
Delivery Time 14 Days
Payment Terms T/T, L/C, Western Union
Supply Ability 10,000 sq.meter/Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Tempered Glass, Clear Glass Laminated Glass, Low-E Glass Glass Color Clear, Blue, Gray, Green, Etc
Advantage Soundproof, Heat Resistant Application Greenhouse, Window, Door, Skylight
Insulating Gas Air, Vacuum, Argon Spacer Type 6A 9A 12A 15A
Structure Hollow Shape Flat, Curved
Leave a Message
Product Description

6A / 9A/ 12A / 15A Reflective​ Insulated Glass For IGU Glass Hollow Glass



Product Description of Reflective Insulated Glass:



Reflective Insulated Glass is a new pyrolytic multi-layers coating and energy efficient product which is used in tropic area and large scale glass building. It is also called reflective insulating glass / reflective coating window glass / reflective double glazing glass / solar control coated insulated glass and so on. It’s durable, easily be tempered, any radius available as hot curved and it can also be used as single panel. The reflective coating has different performance parameter and has many colors. Please contact with our sale engineer to ask for detailed data.



Specification of Low-E Insulated Glass:



Product Name 6A / 9A/ 12A / 15A Reflective Insulated Glass For IGU Glass Hollow Glass
Raw Material Glass Clear Glass, Low-E Glass
Thickness 5+6A+5; 5+9A+5; 5+12A+5; 6+9A+6; 6+12A+6, 6+15A+6 or more
Max Size 2500mm * 3500mm
Min Size 300mm * 300mm
Feature

- High visible light transmission

- Low light pollution

- Best shading effect

- Strong soundproof

- Keep warm or cold environment

Insulating Gas Vacuum
Sample Small Size Free samples provided
Packing Standard export package
Application Freezer Door, Cooler Door, Refrigerator Door, Facades, curtain walls, Skylights, Greenhouse, Window, Door and etc



Performance Features of Reflective Insulated Glass:



1. Large Energy Saving Effect: High-performance insluating glass, due to a special metal film, can reach 0.22-0.49 shielding coefficient, so that the load of indoor air conditioning (cooling) is reduced. The heat transfer coefficient is 1.4-2.8W (m2.K), which is better than ordinary insulating glass. It also plays a great role in reducing indoor heating load. Therefore, the larger the window is opened, the more obvious the energy saving effect.

2. Improve indoor environment: High-performance insulating glass can intercept the considerable energy hit by the sun indoors, thus preventing the discomfort caused by radiant heat and reducing the dazzling caused by the evening sunlight.

3. High transmittance: visible light transmittance near 92%, 6% higher than clear float glass.

4. High Safety: When the glass is damaged by external force, the fragments will be broken into small particles like honeycomb-shaped obtuse angle, which is not easy to cause serious harm to the human body.



Applications of Reflective Insulated Glass:



- Building wall;

- Outer curtain wall;

- Hotel, hospital, shop mall, police station, etc.



Why choose us:

  • Competitive price, value for money
  • Expertise on glass & mirror products
  • Prompt communication & service
  • Quality products
  • On Time Delivery
  • Flexible on order qty & consolidation

Other Products:



Tempered glass

Insulated glass

Laminated glass

Smart glass & self-adhesive PDLC film

Non-reflective glass panels, anti-glare glass panels

Vacuum glass

Stained / fused glass

LED glass, LED mirror
